AudioPressBox
APB-008 FB-EX
Floor box design with 8 routable Line/MIC outputs
A professional press box (Audio Splitter) expander featuring 8 Line/MIC outputs designed for system integrators for fixed installation.
The FB stands for Floor Box as it is for installation into the floor.
Outputs are divided to channel A and channel B so it can also be used for bilingual conferences.
Each Output is independet transformer balanced and isolated.
It has 2 inputs with 3-pin phoenix connectors, one for each Output channel.
You can route each Input to Output Channel A or B or both via jumpers.
It is compatible with floor boxes from OBO Bettermann and PUK.
The expander must be fed with an APB-Drive unit in order to function properly.
REQUIRES A DRIVE UNIT: APB-D100, APB-D100 R, APB-D116 R-DANTE, APB-D200 R, APB-D200 R-DANTE, APB-D216 R-DANTE, APB-208 R, APB-400 R
- 8 High quality balanced Outputs, each Output is independent transformer isolated
- Each Output is switchable between LINE or MIC Output level
- Two groups (A,B) with for 4 Outputs per group
- It is compatible with floor boxes from OBO Bettermann and PUK
- AudioPressBox delivers audio in broadcast quality
Video: APB-008 FB-EX overview
Features
Transformer Separately transformer isolated outputs.
Specification of APB-008 FB-EX
| Type | Expander |
| Groups | 2 |
| Inputs | 1x Bus A ; 1x Bus B |
| Input connectors | ballanced, 3-pin phoenix connector |
| Ouputs | 4x Bus A, Line/MIC level ; 4x Bus B, Line/MIC level |
| Output connectors | ballanced, transformer isolated, XLR-M connector |
| Transformer isolated outputs | Yes (each output) |
| Nominal Output level | MIC: -20dBu ; LINE: +6 dBu |
| Output Impedance | MIC: 220Ω ; LINE: 600Ω |
| Dimensions (WxHxD) | 225x145x50mm |
| Weight | 2190g |
